Muffle Furnace
Model No.: Q26120M1L12
Description
Specification
- Â Heating Element – KANTHAL A-1 wire wounded equally on the muffle
- Â Thermocouple – K-type thermocouple with sensitivity of 41microV/Deg C
- Â Alarm – Audio alarm with blinking light.
- Â Phase – Single phase
- Â Display – LED display
- Â Chamber MO – Double-walled thick with ceramic fibre wool insulation.
- Â Temperature Range – (30 – 1200)0C
- Â Continuous Operating Temperature- (360 – 1150)0C
- Â Volume – (300X200X200) mm cube or 12 Litre
-  Calibration Certificate from NABL-approved Lab – Yes
- Â Temperature Controller Microprocessor-based PID temp. Controller with auto-tune facility for precise control of temperature
- Â Power Rating: 5 kW
- Â Power Supply: Single Phase
- Â Operating Voltage: 220/230 V, Frequency: 50 Hz
-  Programmable (Profile) Temperature Controller -Microprocessor-based PID Profile controller, Programmable up to 8 steps /segment per programme of Ramp/soak Profile, in built memory for resumption of running programme in case of power disturbance, auto switch of on the completion of the cycle, Programmable heating rate up to 5 to 250C /minute.
- Â Insulation – High temperature cerwool insulation.
- Safety Device Fitted – Over heat temperature cut off by safety temperature controller, Electrical overload safety by MCB
- Â Door switch to cut off the heater when open the door, Electrical short circuit breaker by MCB
- Â Exterior MOC – PCRC sheet duly painted
- Â Temperature Accuracy: +/- 10C
- Â Furnace design with high degree of insulation to avoid heat loss and no contact of hot surface to body for heat loss prevention
RELATED PRODUCTS
Muffle Furanace Q25150M13
Product Details
Temperature range: 100-1500 °C
Continuous operating temp: 100-1400 °C
Temperature Accuracy: +/- 1 °C
Heating Element: Kanthal witre
Inner Height: 260 mm, Inner Width: 200 mm, Inner Depth: 250 mm, Volume: 13 Liter
Outer Size W X H X D: 550 mm X 700 mm X 600 mm
Temperature Controller:Programmable profile controller
Thermocouple: K-Type
Alarm: Visual, Audio
Phase: Single, Voltage: 230 V
Chamber: Ceramic High Density Fibre Board
Exterior: Dual Shell housing for low skin temperature Exhaust air outlet at the rear wall of the furnace
Safety Device fitted: Yes
Door: Insulated Solid door with clamp with Drop down door Opening.
Usage/Application Lab
Others: Two way input power*
Muffle Furnace Q23120M3
Product Details
Temperature range: 100-1200 °C
Continuous operating temp: 100-1100 °C
Temperature Accuracy: +/- 1 °C
Heating Element: Kanthal witre
Inner Height: 260mm, Inner Width: 200 mm, Inner Depth: 260mm, Volume: 13.5 Liter
Temperature Controller: Microprocessor control PID controller
Programmable (Profile) Termprature Controller: Yes
Thermocouple: K-Type
Alarm: Visual, Audio
Phase: Single
Chamber: Ceramic High Density Fibre Board
Exterior: Dual Shell housing for low skin temperature Exhaust air outlet at the rear wall of the furnace
Insulation: Ceramic fiber blanket
Safety Device fitted: Yes
Door: Insulated Solid door with clamp
Usage/Application Lab
Others: Two way input power*
Muffle Furnace Q23120M5
Product Details
Temperature range: 100-1200 °C
Continuous operating temp: 100-1200 °C
Temperature Accuracy: +/- 1 °C (+/-1.8 °F)
Heating Element: Kanthal A1
Inner Length: 300mm, Inner Width: 150 mm
Temperature Controller: PID controller
Programmable (Profile) Termprature Controller: Yes
Thermocouple: K Type
Alarm: Audible
Phase: Single
Display: LED
Inner Depth: 300mm, Volume: 13 Liter
Chamber MOC: Ceramic Zirconium Board
Exterior MOC: Mild steel powder coated
Exterior: Dual Shell housing for low skin temperature Exhaust air outlet at the rear wall of the furnace
Insulation: Ceramic fiber blanket
Safety Device fitted: Yes
Door: Insulated Solid door with clamp with Drop down door Opening.
Calibration certificate from NABL approved Lab: Yes
Usage/Application Lab
Others: Two way input power*
Muffle Furnace Q24110M7
Product Details
Temperature range: 100-1100 °C
Continuous operating temp: 100-1100 °C
Temperature Accuracy: +/- 1 °C (+/-1.8 °F), +/- 5°C
Heating Element: Kanthal A1
Inner Length: 300mm, Inner Width: 150 mm
Temperature Controller: PID controller, NA, Microprocessor based Digital TEMPERATURE
Programmable (Profile) Termprature Controller: Yes
Thermocouple: K Type
Alarm: Audible, Visual
Phase: Single, Double, Triple
Display: LED
Inner Depth: 300mm, Volume: 13.0 Liter
Chamber MOC: Ceramic Zirconium Board, Ceramic Low Density Fibre Board, Ceramic High Density Fibre Board, Ceramic Wool,
Bricks, Muffle Baked, Ceramic Wool & Brick with Muffle, Silicon Carbide for energy efficient and better uniformity
Exterior MOC: Mild steel powder coated, Dual shell housing for low skin temperature Exhaust air outlet at the rear wall of the
furnace
Exterior: Dual Shell housing for low skin temperature Exhaust air outlet at the rear wall of the furnace
Insulation: Ceramic ber blanket, Ceramic Mineral Wool, Insulation Bricks, Ultra High Purity Alumina Low Thermal Mass
Insulation
Safety Device fitted: Yes, No
Door: Insulated Solid door with clamp
Calibration certificate from NABL approved Lab: Yes, No
Usage/Application Lab
Others: Two way input power*
Muffle Furnace Q25170M10
Product Details
Temperature range:100-1700 °C
Continuous operating temp: 100-1600 °C
Temperature Accuracy: +/- 1 °C (+/-1.8 °F)
Heating Element: MoSi2
Inner Length: 180mm, Inner Width: 200 mm
Temperature Controller: PID controller
Programmable (Profile) Termprature Controller: Yes
Thermocouple: B- Type
Alarm: Audible
Phase: Single
Display: LED
Inner Depth: 200mm
Volume: 7.0 (liter)
Chamber MOC: Ceramic Low Density Fibre Board, Ceramic Zirconium Board
Exterior MOC: Mild steel powder coated
Exterior: Dual Shell housing for low skin temperature Exhaust air outlet at the rear wall of the furnace
Safety Device fitted: Yes
Door: Insulated Solid door with clamp
Calibration certificate from NABL approved Lab: Yes
Usage/Application Lab
