Muffle Furanace Q25150M13
Product Details
Temperature range: 100-1500 °C
Continuous operating temp: 100-1400 °C
Temperature Accuracy: +/- 1 °C
Heating Element: Kanthal witre
Inner Height: 260 mm, Inner Width: 200 mm, Inner Depth: 250 mm, Volume: 13 Liter
Outer Size W X H X D: 550 mm X 700 mm X 600 mm
Temperature Controller:Programmable profile controller
Thermocouple: K-Type
Alarm: Visual, Audio
Phase: Single, Voltage: 230 V
Chamber: Ceramic High Density Fibre Board
Exterior: Dual Shell housing for low skin temperature Exhaust air outlet at the rear wall of the furnace
Safety Device fitted: Yes
Door: Insulated Solid door with clamp with Drop down door Opening.
Usage/Application Lab
Others: Two way input power*
Description
Product Details
Temperature range: 100-1500 °C
Continuous operating temp: 100-1400 °C
Temperature Accuracy: +/- 1 °C
Heating Element: Kanthal witre
Inner Height: 260 mm, Inner Width: 200 mm, Inner Depth: 250 mm, Volume: 13 Liter
Outer Size W X H X D: 550 mm X 700 mm X 600 mm
Temperature Controller:Programmable profile controller
Thermocouple: K-Type
Alarm: Visual, Audio
Phase: Single, Voltage: 230 V
Chamber: Ceramic High Density Fibre Board
Exterior: Dual Shell housing for low skin temperature Exhaust air outlet at the rear wall of the furnace
Safety Device fitted: Yes
Door: Insulated Solid door with clamp with Drop down door Opening.
Usage/Application Lab
Others: Two way input power*
